KuLNA |
|
Units |
|
频率范围 |
10~13 |
GHz |
|
VCC |
3.3 |
V |
|
I(mA) |
15 |
mA |
|
S11 |
-8 |
dB |
|
S22 |
-12 |
dB |
|
Gain |
20 |
dB |
|
NF |
1.1~1.2 |
dB |
|
P1dB(in) |
-6 |
dBm |
GaAs 0.25um Ku(10GHz～13GHz）
PHMET工艺LNA
|
KuLNA
|
|
Units |
|
频率范围 |
10~13 |
GHz |
|
VCC |
3.3 |
V |
|
I(mA) |
15 |
mA |
|
S11 |
-8 |
dB |
|
S22 |
-11 |
dB |
|
Gain |
21 |
dB |
|
NF |
0.9~1 |
dB |
|
P1dB(in) |
-8 |
dBm |
GaAs 0.15um Ku(10GHz～13GHz）
PHMET工艺LNA
|
KuPA
|
|
Units |
|
频率范围 |
11~15 |
GHz |
|
VCC |
8 |
V |
|
Total supply Current |
250 |
mA |
|
Input Return Loss |
15 |
dB |
|
Output Return Loss |
15 |
dB |
|
Gain |
18 |
dB |
|
saturated output power (psat) |
27 |
dBm |
|
PAE |
26% |
|
|
Output power for 1dB Compression (P1dB) |
26 |
dBm |
|
Output Third Order Intercept (IP3) |
34 |
dBm |
GaAs 0.25um Ku（11GHz～15GHz)
HMET工艺PA
